No dia 10 de Fevereiro a sonda japonesa Kaguya em órbita da Lua gravou um eclipse do sol provocado pela Terra





Successfully Captures Moving Images of the Earth
at the Time of a Penumbral Lunar Eclipse using HDTV


February 18, 2009 (JST)

Japan Aerospace Exploration Agency (JAXA)
Japan Broadcasting Corporation (NHK)

The Japan Aerospace Exploration Agency (JAXA) and the Japan Broadcasting Corporation (NHK) successfully took moving images of the precise Earth rise moment when the Earth looked like a diamond ring using the onboard high definition camera (HDTV) of the lunar explorer "KAGUYA" (SELENE) on February 10, 2009 (Japan Standard Time, all the following dates and times are Japan Standard Time.) The moment came when a penumbral lunar eclipse occurred and sunlight was covered by the Earth. During that time, since the view of the Sun from the KAGUYA was mostly covered by the Earth, the KAGUYA observed that the Earth looked like a diamond ring. This is the first time that this phenomenon was shot from the Moon.

The images were shot by the HDTV onboard the KAGUYA for space-use developing by NHK. The moving images were received at JAXA and processed at NHK.

* A penumbral lunar eclipse is a phenomenon in which the Sun, Earth and Moon line up in tandem, hence the Moon is in the Earth's penumbra, or, when you look from the Moon, the Sun is partially covered by the Earth (partial eclipse.) During this phenomenon, the volume of sunlight to the Moon decreases, and the Moon's surface looks darker when you look at the Moon from the Earth. The KAGUYA, which circles around the Moon on its polar orbit, can witness this phenomenon only twice a year at most, thus it was very valuable to capture the moving images of the phenomenon from the KAGUYA.

Figure 1 Image of the Earth by the HDTV (Tele-camera) during the penumbral lunar eclipse



This still image was a cutout from the moving images taken by the onboard HDTV (tele-camera) of the KAGUYA (SELENE) on February 10, 2009. The bright part on the lower right side is the Sun and the black area surrounded by the thin light ring is the Earth. The red dotted line shows the Moon's surface. Most of the Sun is covered by the Earth and the Moon's surface.


Figure 2 Sequence images of the Earth by the HDTV (Tele-camera)
during the penumbral lunar eclipse



The KAGUYA captured the moving image of the Earth and the Sun gradually rising from the Moon's surface. The above sequence of images is a cutout from the moving image to show the rising process. The image on the far left is just after the Earth rise from the Moon's surface. It took about 47 seconds to film from the left to the right when the Sun came out from the Moon's surface and the diamond ring appeared.




Figure 3 Positions of the KAGUYA, Moon, Earth and Sun
when images of the Earth-rise during the penumbral lunar eclipse

http://www.jaxa.jp/press/2009/02/20090218_kaguya_e.html
